Description

ThinkPad T15p Gen 1

Part Number : 20TN001QTX

PERFORMANCE
Processor
Intel Core i5-10300H (4C / 8T, 2.5 / 4.5GHz, 8MB)
Graphics
Integrated Intel UHD Graphics
Chipset
Intel WM490
Memory
1x 16GB SO-DIMM DDR4-2933
Memory Slots
Two DDR4 SO-DIMM slots, dual-channel capable
Max Memory
Up to 64GB DDR4-2933
Storage
256GB SSD M.2 2280 PCIe 3.0×4 NVMe Opal2
Storage Support
Up to two drives, 2x M.2 2280 SSD • M.2 2280 SSD up to 2TB • RAID 0/1 support
RAID Preset
None
Card Reader
SD Reader
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio
Camera
720p + IR with ThinkShutter
Microphone
2x, Array
Battery
Integrated 68Wh
Max Battery Life
MobileMark 2014: 12.1 hr MobileMark 2018: 7.9 hr
Power Adapter
135W Slim Tip
DESIGN
Display
15.6″ FHD (1920×1080) IPS 250nits Anti-glare
Touchscreen
None
Keyboard
Backlit, Turkish
Case Color
Black
Case Material
PC + ABS (Top), PC + ABS (Bottom)
Dimensions (WxDxH)
366.5 x 250 x 22.7 mm (14.43 x 9.84 x 0.89 inches)
Weight
2.07 kg (4.57 lbs)
SOFTWARE
Operating System
None
Bundled Software
None
CONNECTIVITY
Ethernet
100/1000M
WLAN + Bluetooth
Intel AX201 11ax, 2×2 + BT5.2
WWAN
WWAN Upgradable
SIM Card
None
NFC
None
Standard Ports
  • 1x Ethernet (RJ-45)
  • 1x USB 3.2 Gen 1
  • 1x USB 3.2 Gen 1 (Always On)
  • 1x headphone / microphone combo jack (3.5mm)
  • 1x HDMI 2.0
  • 1x USB-C 3.2 Gen 2 / Thunderbolt 3 (support data transfer, Power Delivery and DisplayPort 1.2)
  • 1x SD card reader
Optional Ports
  • 1x Smart card reader
  • 1x Nano-SIM card slot (WWAN models)
Monitor Cable
None
SECURITY & PRIVACY
Smart Card Reader
Smart Card Reader
Security Chip
Discrete TPM 2.0
Fingerprint Reader
Touch Style, Match-on-Chip
Physical Locks
Kensington Security Slot
Other Security
  • IR camera for Windows Hello
  • ThinkShutter camera cover
MANAGEABILITY
System Management
None
SERVICE
Base Warranty
3-year, Depot
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
  • ENERGY STAR 8.0
  • TCO
  • EPEAT Gold
  • RoHS compliant
Mil-Spec Test
MIL-STD-810G military test passed
